产品描述：
★参考标准：SAE J 1128
★耐高温，耐油，耐磨损和耐寒
★极佳的柔韧性
★绞铜线
★可提供颜色，条纹和环纹
★经第三方实验室验证
★符合无铅无镉要求
★用途：汽车内部配线及硬度高的地方需要高柔韧性，热和机械强度
| AWG | Size mm² | Conductor | Insulation | Maximum Resistance at 20℃ Ω/km | ||
| No./mm | Nom. Dia. mm | Nom. Thick. mm | Nom. Dia. mm | |||
| 24 | 0.22 | 7/.019 | 0.6 | 0.4 | 1.5 | 88.9 |
| 22 | 0.35 | 7/.026 | 0.8 | 0.4 | 1.7 | 50.2 |
| 20 | 0.50 | 7/.032 | 1.0 | 0.4 | 1.9 | 32.7 |
| 18 | 0.80 | 19/0.23 | 1.2 | 0.4 | 2.2 | 24.4 |
| 16 | 1.00 | 19/0.28 | 1.4 | 0.4 | 2.4 | 14.3 |
| 14 | 2.00 | 19/0.35 | 1.8 | 0.4 | 2.7 | 8.8 |
