UL10602

UL10602

★ Rated temperature: 80℃ Rated voltage: 300V

★ Reference Standard: UL Subject 758, UL1581 & CSA C22.2 NO.210.2, IEC60754-2

★ Tinned or bare, tinned or silver plated, stranded or solid copper conductor, 40-16 AWG

★ Colour-coded FRPE insulation

★ Uniform insulation thickness to ensure easy stripping and cutting

★ Passes UL VW-1 & CSA FT1 vertical flame test

★ Application: For internal wiring of  electronic and electrical equipment


ConductorInsulationMaximum Resistance at 20 ℃
Ω/km
AWGNo./mmDia.
mm
Nom. Thick.
mm
Nom.Dia.
mm
307/0.10.300.260.82354
287/0.1270.380.260.90223
267/0.160.480.261.00139
2411/0.160.610.261.1388.9
2217/0.160.760.261.2857.5
2026/0.160.940.261.4634.6
1841/0.161.180.261.7023.3
1626/0.2541.490.262.0115.1
