产品描述：
★额定温度：80ºC
★额定电压：300V
★根据：UL Subject758，UL62，C22.2
★导体使用单条或绞线镀锡或裸铜32--16AWG
★PVC绝缘
★通过UL VW-1 FT1垂直燃烧测试
★电线绝缘厚度均匀，易于剥线和切割
★用于家用电器的通用内部接线
| Conductor | Finished Products | |||
| AWG/NO.OFCOND | AWG | Cond No. | Nom.thick | Nom.Dia |
| Size | /mm | mm | m/m | |
| 2 to 12 | 26 | 7/0.16 | 0.38 | 1.35 |
| 24 | 11/0.16 | 1.45 | ||
| 22 | 17/0.16 | 1.65 | ||
| 20 | 21/0.18 | 1.85 | ||
| 18 | 41/0.16 | 2.1 | ||
| 16 | 26/0.253 | 2.4 | ||
